Thunderbolt Dock
Overview
Adds three Thunderbolt and four USB ports, along with Ethernet, audio, and card reader functionality to Thunderbolt 3 Macs or Thunderbolt 4 PCs. The OWC Thunderbolt Dock lets you create three separate “tree branches,” so you can remove devices from one chain without affecting or disconnecting the other. You can even take things up a notch by adding three Thunderbolt bus-powered devices.
Connect more storage, up to two 4K displays or one 5K/6K/8K display, and accessories... you name it, you can use it. You can connect and charge through the USB. Access photos and movies via the SD card reader at speeds up to 312MB/s. Certified for Mac and Windows.
Secure
Kensington Security Slot™ and Nano Security Slot™ for anti-theft cabling. Gigabit Ethernet eliminates low-quality, patchy Wi-Fi — ideal for IP-based workflows and secured networks.
Specs and Pricing
Class/Tier: Dock-OWCTBdock
Ports: 14
Hardware Interface: Any Mac or Windows PC with a built-in Thunderbolt 3 port
Display Support: Supports up to one 5K display at 60Hz or two 4K displays at up to 60Hz2
OS Compatible: Mac and Windows
Estimated Price: $294
Connectivity
Ports and Slots
1. 1 - microSD 4.0 media card reader
2. 1 - SD 4.0 media reader
3. 1 - Hybrid 3.5 mm headphone/mic jack
4. 1 - USB 3.1 Gen 2 Type-C port - power delivery 5V up to 3A (15W)
5. 1 - USB 3.1 Gen 1 Type-A port - compliant with Battery Charging 1.2 spec
Back Interface:
1. 1 - Thunderbolt 3 (USB Type-C) dedicated power delivery port supporting up to 85W
2. 1 - Thunderbolt 3 (USB Type-C) port
3. 1 - Mini DisplayPort 1.2 (supports DP++)
4. 4 - USB 3.1 Gen 1 Type-A ports - with one port compliant with Battery Charging 1.2 spec
5. 1 - Gigabit Ethernet port
6. 1 - S/PDIF digital audio output port
Power: External UL-listed universal auto-switching
AC input: 100 ~ 240V, 50/60Hz
DC output: 20V, 9A
Dimensions: 1x9x3.5 inches
